The CS332 Magic Lantern Controller launched June 2016..is available to order now......
Copyright © 2016 by Cellsun UK · All Rights reserved · E-Mail: sales@celsun.com
keeping a eye on your image quality
CS332 Controller Specifications
The CS332 Controller attaches to the LED Lime-Lights in seconds with secure XLR plugs. Mains power to the unit is connected by a standard IEC cable via the right hand side panel switched socket. Once the power is switched on there is a brief calibration cycle where the electronics checks the unit and it is ready for the show.
Celsun CS332 rear view sockets
| Lamp outputs |
3 |
| Each output |
Constant current mode for LED 37 Volts Max 2.8 Amps MAX
XLR 5pin socket per output |
| Dimming |
0 to 100% x master 0 - 100 |
| Power supply |
200-250 VAC 50/60Hz
or with internal PSU switch
100- 125VAC50/60Hz |
| Power consumption |
400 Watts Max |
| Console dimensions |
305mm x 165mm x 105mm |
| Weight |
3.5 Kgs / 8lbs |
| Power Inlet |
Switched IEC Socket with neon |
| Compatible Lamps |
Celsun CS331 100 Watt LED |
| USB Reading Light Socket |
3 watts MAX at 5 volts |
